The 20kw 30kw 40kw portable quick-charger was developed for electric vehicles with CHADEMO
or CCS Combo DC charging sockets and is designed for semi-mobile use.
DC Portable Charger 20KW 30kw 40kw CCS2 Fast Mobile Charging Station
Model:MIDA-PD-30KW
Rated voltage:DC 400V
Input Rating:380Vac± 15%
Power Factor:>0.99 @ full load
TFT-LCD Touch Panel:4.3' touch display
Certification:CE ROHS
PRODUCT INTRODUCTION:
20kw 30kw 40kw Portable quick charger supports CCS and CHAdeMO only by replace the cable. USB for firmware update and RJ45 port for internet connect(optional). Open door design, it is convenient to replace power module.This charger is perfect to install for charging electric vehicle at maximum speed as well as many EV cars take in road trips through rural areas with RV or industrial areas being the main power sources for ev travelers.
✔ Small size and compact design, easy for portable
Mobile Charger 20kw 30kw 40kw Portable DC Charger Station
✔ It is supporting CCS and CHAdeMO connector
✔ Certification: CE/IEC/ROHS
✔ Protection Degree: IP54
✔ Open door design, it is very convenient to replace power module.
AC Input
1. Input Rating:400Vac± 15%
2. AC Input Connection:3P+N+PE (Wye connection)
3.Max. Input Current:50A
4.Efficiency: 95%
DC Output
1. Output Voltage Range:50~500Vdc (CHAdeMo), 150~750Vdc (CCS), 48~450Vdc(GB/T)
2. Max.Output Power:20KW,30kW,40kw
3Max.Output Current:100A@500V,
User Interface
1. TFT-LCD Touch Panel:4.3' touch display
2.Push Buttons:Emergency Stop
3. Interface:USB, RJ45
Packing
1.Dimension:630*230*632mm
2.Weight:35KGS
Environment
1. Operating Temperature: -20°C ~ +50°C, power derating from +50°C and above
2. Humidity: 5% ~ 90% RH, non-condensing
3.Altitude: 2000m
4.IP Level: IP23
Regulation
1.Regulation: IEC61851-1
2.Certification: CE,ROHS
3. Charging protocol: CHAdeMO 2.0/DIN 70121/ISO15118/IEC61851-23
