DC EV Charging Station

Multi-standard DC Charging Station

Simultaneously charging up to 3 EVs

• Flexible configurations 60kw 80kw 100kw 120kw 160kw 180kw 240kw DC Charging Station
• Supporting CCS, CHAdeMO, GB/T, and Type 2 AC charging
• Ethernet, Wi-Fi, 4G connection
• OCPP 1.6J & OCPP 2.0
• Smart charging supports dynamic load balancing

  Easy to Use

  • 8’’ LCD touch screen with multi-language interface
  • Secure authentication and payment through RFID, mobile Apps, or POS
  • Plug & Charge optional


  Wall-mount or Pedestal-mount

  • Multi-standard Charging

    • Supports CCS, CHAdeMO, GB/T, and AC connectors. Charging up to 3 vehicles at the same time
    • Triple outlet ports, two DC cables, one AC cable, and one 3.6kW schuko output

  General Specifications

  Item	PowerDC 60kW; AC 22kW/44kW	DC 90kW; AC 22kW/44kW	DC 120kW; AC 22kW/44kW
  Input	Input Voltage	3-phase 400V ±15% AC
  	Input Voltage Type	TN-S (Three Phase Five Wire)
  	Working Frequency	45~65Hz
  	Power Factor	≥0.99
  	Efficiency	≥94%
  Output	Rated Voltage	DC - CHAdeMO 500Vdc; CCS 1000Vdc; GBT 1000Vdc; AC - Type-2 400V; GBT 400V
  	Max. Output Current	DC - CHAdeMO 125A; CCS 200A; GBT 250A;	AC - Type-2 63A; GBT 32A
  Interface	Display	8'' LCD Touchscreen
  	Language	Chinese, English, French, German, Spanish, Russian, etc.
  	Payment	Mobile APP/RFID/POS
  Communication	Network Connection	4G(GSM or CDMA)/Ethernet
  	Communication Protocols	OCPP1.6J or OCPP2.0
  Working Environment	Working Temperature	-30°C  ~ +55°C
  	Storage Temperature	-35°C  ~ +55°C
  	Operating Humidity	≤95% Non-Condensing
  	Protection	IP54
  	Acoustic Noise	<60dB
  	Cooling Method	Forced Air-Cooling
  Mechanical	Dimension(W x D x H)	700*1900*650mm
  	No. of Charging Cable	Single	Dual
  	Cable Length	5m or 7m
  Regulation	Certificate	CE/IEC61851-1/IEC61851-23/IEC61851-21-2
